DIA-RTR.MD5
Tenon tool for cabinet door mitre applications. PCD cutting tool provides excellent wear resistance in abrasive materials.
Diameter (D) | 61mm |
Shank (Sh) | 0.750" |
Overall Length (OA) | 117mm |
Number of Wings/Flutes/Teeth (Z) | 3+9 |
Material (Material) | DP |
Rotation (Rotation) | RH |
Dimension Variable 1 (b1) | 0.500" |
Dimension Variable 2 (b2) | 65mm |
Small Diameter (Ds) | 2.000" |
Machines


Pillar M Series
Pillar M series miter machines for cabinet doors


Omal Miter
CNC Round end tenon machine for producing miter joints for cabinet doors and furniture parts
