DIA-RTR.DTD.312R
Dovetail tool for use on Dodds dovetail machines. Diamond cutting edge provides 50-100 times the life in MDF, plywood, and most hardwoods. 5/16" - 24 Thread
Diameter (D) | 14mm |
Shank (Sh) | 0.3125" |
Overall Length (OA) | 2.000" |
Number of Wings/Flutes/Teeth (Z) | 2 |
Material (Material) | DP |
Rotation (Rotation) | RH |
Dimension Variable 1 (b1) | 0.349" |
Dimension Variable 2 (b2) | 1.157" |
Small Diameter (Ds) | 11mm |
Machines
Dodds Dovetailers
SE model Dodds machines for dovetail drawer boxes
